SPECIFICATIES

• Nominal Input Level: -20 dBu
• Input Impedance: 1 M ohm
• Nominal Output Level: -20 dBu
• Output Impedance: 1k ohm
• Recommended Load Impedance: 10k ohms or greater
• ControlsPedal switch: LEVEL knob, LOW knob, HIGH knob, DRIVE knob
• Indicator: CHECK indicator (Serves also as battery check indicator)
• Connectors: INPUT jack, OUTPUT jack, AC adaptor jack (DC 9 V)
• Power Supply: Alkaline battery (9V, 6LR61) or Carbon-zinc battery (9V, 6F22), AC adaptor (sold separately)
• Current Draw: 45 mA
• Expected battery life under continuous use : Alkaline: Approx. 9 hours, Carbon: Approx. 2.5 hours
  * These figures will vary depending on the actual conditions of use.
• Accessories: Owner’s Manual, Leaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTE,” and “Information”), Alkaline battery (9V, 6LR61)
• Option (sold separately): AC adaptor (PSA series)
• Width: 73 mm, 2-7/8 inches
• Depth:129 mm, 5-1/8 inches
• Height: 59 mm, 2-3/8 inches
• Weight: 450 g, 1 lbs.
